When to Use Wheel Spacers (Or Your Wheels Just Won’t Fit)
Most people think spacers are just for style or stance. But sometimes, you have no choice. In this guide, we’ll show you the exact situations where using wheel spacers is absolutely necessary — or your wheels simply won’t mount.
⸻
🚗 What Are Wheel Spacers?
A wheel spacer is a metal ring that sits between your car’s hub and the wheel. It pushes the wheel outward by a few millimeters or more — typically 3mm to 30mm per side.
Most people use spacers for:
• Wider stance
• Flush fitment
• Clearance for big brake kits
• Better aesthetics
But sometimes, spacers aren’t optional — they’re mandatory.
⸻
⚠️ When Do You Have to Use Spacers?
Let’s break it down:
⸻
1. 🛑 Your Wheel Hits the Brake Caliper
If your aftermarket wheels have insufficient inner clearance, they’ll contact the brake caliper — especially with:
• Big brake kits (Brembo, Wilwood, StopTech)
• Thin-spoke designs
• Deep concave wheels
❗ In this case, spacers are required to push the wheel away from the caliper — even as little as 3mm can make the difference.
⸻
2. 🧩 Center Bore Interference
Some wheels, especially multi-fit or universal designs, may not sit flush on your hub due to:
• Slight lip interference
• Improper machining
• Paint or corrosion buildup
Adding a 3–5mm spacer gives the wheel enough breathing room to seat properly.
⸻
3. 🔩 Bolt or Nut Collision
If you’re using:
• Aftermarket studs
• Spacers with recessed holes
• Closed-end nuts on long bolts
…you may find the bolts bottoming out or pressing against the hub face.
Adding spacers solves this instantly.
⸻
4. 🛠 Your Offset Is Too High
If you’re running a wheel with too much positive offset, it sits too far inside the fender, which:
• Looks bad
• Can rub on suspension or fender liners
• May affect brake lines or sensors
A 10–20mm spacer helps push the wheel outward for correct clearance and style.
⸻
5. 🌀 The Wheel Simply Won’t Mount
Yes, this happens. You install a fresh set of wheels…
…and the barrel touches the strut or control arm before the bolts even tighten.
👉 That’s when a spacer becomes the only solution to even mount the wheel on your vehicle.
⸻
🧪 Real-World Example: No Spacer, No Fit
We recently test-fitted a 19×9.5 ET40 wheel on a 2021 Lexus IS300 F-Sport.
Without a spacer:
• The inner barrel hit the front brake caliper.
• The wheel wouldn’t turn at all.
With a 5mm hub-centric spacer:
• Cleared the caliper.
• No vibration.
• Perfect torque + road test passed.
⸻
⚙️ How to Choose the Right Spacer
If you’re forced to use a spacer, do it properly:
✅ Always go hub-centric
✅ Match the center bore and PCD exactly
✅ Use extended bolts or studs for anything over 5mm
✅ Torque to OEM spec
✅ Retorque after 100 km
⸻
🔗• Shop Hub-Centric Wheel Spacers
• Lug Bolts for Spacers
⸻
🚘 Why Knowing When to Use Wheel Spacers Can Save You Time and Money
Many drivers only realize when to use wheel spacers after installing a new set of wheels — and facing unexpected issues. Whether it’s a rubbing noise, a bolt that won’t torque, or a wheel that simply won’t sit flat, the problem is often solved by adding the right spacer. But by the time you realize it, you may have already wasted hours at the shop or damaged expensive wheels or brake parts.
Understanding when to use wheel spacers from the beginning saves you the trouble. For example, if your wheels are custom or have an unusual offset, you should always test-fit them first. The moment you notice that the wheel barrel is uncomfortably close to the suspension, or if the caliper is even slightly rubbing — that’s when to use wheel spacers without question.
⸻
🛞 Common Vehicles That Often Require Spacers
Certain vehicles are more prone to clearance issues, and knowing when to use wheel spacers is especially important for them:
• Tesla Model 3/Y: Narrow inner clearance around calipers
• Mustang GT: Needs spacers for deep concave wheels
• Nissan 350Z/370Z: Often uses spacers to fix high OEM offset
• Mercedes AMG & Audi RS: Performance brake kits interfere with many aftermarket rims
So if you’re installing aggressive fitment wheels or switching brands, it’s smart to know when to use wheel spacers before the issue appears.
⸻
💡 Bonus Tip: Don’t Wait for the Problem
Most people wait until there’s a problem — a wheel doesn’t turn, rubs, or won’t torque down properly. But experienced tuners already know when to use wheel spacers by measuring wheel specs, offset, hub bore, and brake clearance in advance.
You don’t have to guess. Just remember:
• If it rubs, add a spacer.
• If it vibrates, use hub-centric spacers.
• If it won’t mount, it’s time for spacers.
⸻
🎯 Conclusion
If there’s one mod that’s both simple and crucial, it’s a spacer. But only when you use wheel spacers in the right situation, with the right specs, will they help your fitment — instead of causing problems.
⸻
